I. Product Information
The perfume vacuum filler is pure pneumatic equipment, it can work by air compressor as power. this perfume vacuum filler especially suitable for perfume, toilet water, and other small doses of filling.
this machine adopts vacuum filling principles, the filling level will remain the same regardless of the different volume of the bottles. This series of perfume vacuum filler are easy to operate. The operator can do filling by stuck the bottle head under the filling nozzle or by pedal.
Main features of the perfume vacuum filler
1.pure pneumatic, meet explosion-proof requirements;
2. configure automatic drainage system, make sure the material back to the barrel;
3. no strict requirements the about bottle shape and consistency;
4. simple structure, easy operation and maintenance;
5. suitable for a small dose of liquid filling;
6. no need other power supply, affordable.
7. vacuum filling , setting liquid level
II. Technical Data
Model
JX-04
Gas pressure
0.5-0.8 MPa
Viscosity range
the biggest applicable viscosity 20 Cps (static viscosity)
Production capacity
50 bottles/minutes
Bottles height
more than 250 mm
Bottle mouth diameter
than4.5 mm-35 mm
Adjustable liquid surface height (from bottle mouth)
15-50 mm
Shape dimension (not including store liquid bottle)
660 * 470 *1330 mm
Air extraction rate
5.5 liters/Sec
III. Product Show
