I.Product Information
1) Liquid filling machine can do both automatic and semiautomatic filling and uses the air compressor as the power to work, only a little electric power for the indicator light. So this machine can work at any explosive or combustible environment by just stepping on the pedal or switch to automatic mode.
2) This liquid filling machine is suitable for all kinds of liquid, such as juice, yogurt, oil, water etc it is the ideal filling equipment of pharmaceutical, chemical, food, cosmetics and other industries.
3) This machine does self- priming filling. Driven by the air cylinder, the piston pump liquid material into measuring cylinder, then the piston push the liquid into to the bottle.
4) The machine is with single nozzle and double nozzle for choice.
Features
1) This liquid filling machine is pneumatic piston type and work by air compressor as power.
2) This machine has reasonable structure, compact shape, convenient operation. the pneumatic parts adopts Germany FESTO and
Taiwan AIRTAC starting component.
3) The fact that the part in contact with the material is made of 304# stainless steel, which brings qualified anti-corrosion performance,
meeting with the GMP standard.
4) Filling volume and filling speed can be adjusted, and the precision is high.
5) Filling head adopts anti-leakage and lifting device.
6)Volumetric pump, so filling volume is adjustable and controllable.
7)The liquid filling machine has the features of simple structure, reliable and convenient adjustment.
II. Technical Data
Model |
RBGY |
Voltage |
220V 50/60Hz |
Air pressure |
0.4-0.6 MPa |
Dimension |
1100×300×400mm (20-500ml type ) |
Filling range |
5-100ml, 20-300ml 20-500ml,50-500ml, 100-1000ml, 300-2000ml,500-3000ml,1000-5000ml |
Filling precision |
error ≤± 1% |
Filling speed |
0-25 bottles / min |
Weight |
30KG(20-500ml type ) |
Dimension |
1100*300*400mm(20-500ml) |
III.Single nozzle and double nozzle liquid filler
IV. Products show(filling volume can be adjusted within range)
