Semi auto cork plug machine

Products list
Updated:2017-08-16

I. Product  Information

 It is a specialized machine for producing kinds of glass bottled wine, red wine, fruit wine, grape wine, white wine, champagne, bubbly and so on .

The cork will be put into the extruding cork device automatically by feeder,

Simple operate, Safe and reliable, High quality, Save labor, The machine is portable compact, rational design ,Wide applicability, easy to maintenance, Durable.

 Press cork without dregs. The cork presser is loaded in cork sorting machine. It will arrange corks automatically and then caps are dropped down alone the track.

The middle pillar of corker is adjustable, do not need to change parts, can cork the height 360mm of bottle.

 II.Technical Data

Model

 RBG

production capacity

1200-1500 bottles/hour

applicable bottle height

60-360mm

Bottles mouth diameter

15-25 mm

Motor

220v/380v,0.75kw

Cork diameter

20-25mm

Cork height

30-45mm

Outline dimension

650*250*1125mm

Weight of machine

130kg

III.Product Show
