Automatic flat bottle labeling machine

Products list
Updated:2017-08-18


I.Product Information

Function character:

1.It adopts standard PLC,  touch screen, standard sensor electronic control system, human-computer interface in Chinese and English notes and improve the function of fault tips,

thus guaranteeing accurate labeling, stable, reliable and high efficiency.

2.Operational guidance functions, troubleshooting instructions; easy to use and easy maintenance;

no product non-labeling, non-sticker auto correction and automatic detection function ;

3.With system check function: labels lacking or broken, leaving out, e-stop, abnormal frequency-conversion, typewriter ribbon lacking, it can detect all & then stops auto.

4.Also can match with batch coder or printer coder function.

5.The self-check function, can display all system photoelectric signals & motor, shorten repair time, reduce maintenance cost.
6.With step less speed control, labeling speed automatically changes according to conveying speed, no need to move labeling sensor.
Made of SUS304 & alumni alloy, totally meeting GMP requirements.

II.Technical Data

Model

MT-220

Working speed

0-220pcs/min

Label size

L:20-300mm W: 10-90mm

Accuracy

±1mm

Max label outer diameter

ф300mm

Max label inner diameter

ф75mm

Power

110V/220 50/60HZ 500W

Machine size

1600×600×1400mm

Weight

110V/220 50/60HZ 500W

III.Suitable for flat bottle labeling automatically
